120 6400WMCX03A Speaker, Woofer G1560102 ND35 15W 8OHM 82DB 100HZ 193X57mM LUG

121 6400DTTX02C Speaker, Tweeter EN15D-6659-1 N35 15W 8OHM 81DB - 38.3X88mM LUG

200 6348Q-E113H PDP, Module-VGA PDP42V80201.AKLGG VGA 42INCH 852X480 16/9

201 6871QCH074A PCB Assembly, Display CTRL ASSY HAND INSERT 42” 42V8 4005 ASIC LVDS

202 6871QDH118A PCB Assembly, Display YDRV ASSY HAND INSERT 42” 42V8 80PIN SCAN IC APLICATION

203 6871QLH057A PCB Assembly, Display XRLT ASSY HAND INSERT 42” 42V8 XL 4004 ASIC LVDS

204 6871QRH067A PCB Assembly, Display XRRT ASSY HAND INSERT 42” 42V8 XR 4004 ASIC LVDS

205 6871QYH048A PCB Assembly,Display YSUS ASSY HAND INSERT 42” 42V8 Y SUS B/D

206 6871QZH053A PCB Assembly,Display ZSUS ASSY HAND INSERT 42” 42V8

240 4980900109A Supporter, COMPLEX ASSY AL 42PC1R-TA, VERTICAL RIGHT

250 4980900109B Supporter, COMPLEX ASSY AL 42PC1R-TA, VERTICAL LEFT

300 30919E0006E Cover Assembly, 42PC1V-AA BRAND 30909E0001A NON

301 4980900113A Supporter, COMPLEX ASSY AL FILTER TOP 42PC1R-TA

302 4980900114A Supporter, COMPLEX ASSY AL FILTER BOTTOM 42PC1R-TA

303 4980900115A Supporter, COMPLEX ASSY AL FILTER RIGHT 42PC1R-TA

304 4980900116A Supporter, COMPLEX ASSY AL FILTER LEFT 42PC1-TA

400 3809900103B Cover Assembly, 42PC1D NON DIGITAL

430 3501900014A Base Assembly, D/T SPK STAND AP-42DC11 MF056A FOLDING STAND

501 3301900095H Plate Assembly, AV 42PC I-DTV

502 3301900092A Plate Assembly, ASSY DIGITAL COVER ASSY (PB61A)

520 68719MMV65A PCB Assembly, Main MAIN1 M.I PB61A 42PC1DV-AA AAULLHX AUSTRAILIA DTV DIGITAL MANUAL

530 68719SMK96A PCB Assembly, Sub SUB M.I PB61A 42PC1DV-AA AAULLHX AUSTRAILIA DTV TUNER MANUAL

560 68719SMK74A PCB Assembly, Sub SUB M.I PB61A 42PC1DV-AA AAULLHX AUSTRAILIA DTV LOCAL ASSY MANUAL

570 68719SMJ64A PCB Assembly, Sub SUB M.I PP61A 42PC3RV Z PREAMP+LED

580 68719PT299A PCB Assembly, Power POWER T.T PA61A 42INCH PDP UNIFICATION PSU ALL GUMI

600 68719SML57A PCB Assembly,Sub SUB M.I PB61A 42PC1DV-AA AAULLHX AUS DTV SIDE AV MANUAL

611 4811900021D Bracket Assembly, SIDE AV 42PC1RV-TH PP62A CORTEZ, NON EU

612 48149V0003A Plate, PRESS SPTE T0.3 SIDE AV 42PC1R

EXPLODED VIEW PARTS LIST

No. Part No. Descriptions

The components identified by mark is

critical for safety.

Replace only with part number specified.
