LG 42PC1RV/RVA User Manual

- 20 -
2. No Power
(1) Symptom
1) Front LED is NO light.
2) The Set doesn’t discharge little.
(2) Check following
Is plug in power cord? Plug in power cord.
Yes
No
Is the Line Filter Cable to PSU
connected?
Connect the Cable.
Yes
No
Is the Fuse(F101) on
PSU normal?
Exchange the Fuse.
Yes
No
Is the PSU and Main Board with
13P Cable connected?
Connect a 13p Cable.
Yes
No
After the cable connect is remved
to Power Board(except the EL11
connection cable), the AC voltage
marking is authorized on manual.
When ST-BY 5V is not operated,
replace PSU.

LG 42PC1RV/RVA Specifications

General

Display Technology	Plasma
Resolution	1024 x 768
Aspect Ratio	16:9
Contrast Ratio	10000:1
Brightness	1500 cd/m²
Power Consumption	300 W
Screen Size	42 inches
Component Video Inputs	2
Composite Video Inputs	2
S-Video Inputs	1
Viewing Angle	160°
Input Ports	HDMI, Component, Composite, S-Video
HDMI Ports	1
