LG 42PC1RV/RVA User Manual

- 31 -
120 6400WMCX03A SPEAKER, WOOFER G1560102 MACOM WOOFER 8OHM 15/20W 82DB OTHERS 100HZ 193*57MM
121 6400DTTX02B SPEAKER, TWEETER EN15D-6659 TOPTONE TWEETER(DOME) 8OHM 15/20W 78DB OTHERS PC1 MODEL
200 6348Q-E113H PDP, 42” 852*480 PDP42V80201.AKLGG 42PC1RV-ZJ CIS SET
6348Q-E127T PDP, 42 852*480 PDP42V80201.ADLGB
201 6871QCH074A PWB(PCB) ASSEMBLY, DISPLAY CTRL ASSY HAND INSERT 42 42V8 4005 ASIC LVDS
202 6871QDH118A PWB(PCB) ASSEMBLY, DISPLAY YDRV ASSY HAND INSERT 42 42V8 80PIN SCAN IC APLICATION
203 6871QLH057A PWB(PCB) ASSEMBLY, DISPLAY XRLT ASSY HAND INSERT 42 42V8 XL 4004 ASIC LVDS
204 6871QRH067A PWB(PCB) ASSEMBLY, DISPLAY XRRT ASSY HAND INSERT 42 42V8 XR 4004 ASIC LVDS
205 6871QYH048A PWB(PCB) ASSEMBLY, DISPLAY YSUS ASSY HAND INSERT 42 42V8 Y SUS B/D
206 6871QZH053A PWB(PCB) ASSEMBLY, DISPLAY ZSUS ASSY HAND INSERT 42 42V8
240 4980900109A SUPPORTER, ASSY AL 42PC1R-TA, VERTICAL RIGHT 42PC1RV-ZJ CIS SET
4980900109C SUPPORTER, ASSY AL 42PC1R-TA, VERTICAL RIGHT, C/SKD
250 4980900109B SUPPORTER, ASSY AL 42PC1R-TA, VERTICAL LEFT 42PC1RV-ZJ CIS SET
4980900109D SUPPORTER, ASSY AL 42PC1R-TA, VERTICAL LEFT, C/SKD
300 30919E0006A CABINET ASSEMBLY, 42PC1RV-ZJ BRAND 30909E0001A 42PC1RV-ZJ CIS SET
30919E0006C CABINET ASSEMBLY, 42PC1RV-TJ(CHINA) BRAND 30909E0001A-> 42PC1RVA-ZJ
30919E0006H CABINET ASSEMBLY, 42PC1RV-ZJ BRAND 30909E0001A C/SKD -> 42PC1RV-ZJ
301 4980900113A SUPPORTER, ASSY AL FILTER TOP 42PC1R-TA 42PC1RV-ZJ CIS SET
4980900113B SUPPORTER, ASSY AL FILTER TOP 42PC1R-TA C/SKD
302 4980900114A SUPPORTER, ASSY AL FILTER BOTTOM 42PC1R-TA 42PC1RV-ZJ CIS SET
4980900114B SUPPORTER, ASSY AL FILTER BOTTOM 42PC1R-TA C/SKD
303 4980900115A SUPPORTER, ASSY AL FILTER RIGHT 42PC1R-TA 42PC1RV-ZJ CIS SET
4980900115B SUPPORTER, ASSY AL FILTER RIGHT 42PC1R-TA, C/SKD
304 4980900116A SUPPORTER, ASSY AL FILTER LEFT 42PC1-TA 42PC1RV-ZJ CIS SET
4980900116B SUPPORTER, ASSY AL FILTER LEFT 42PC1-TA, C/SKD
400 3809900103A BACK COVER ASSEMBLY, 42PC1R ANALOG 42PC1RV-ZJ CIS SET
3809900103P BACK COVER ASSEMBLY, 42PC1 LGEMA ASSY ONLY (ANALOG)
430 3501900014A BOARD ASSEMBLY, D/T SPK STAND AP-42DC11 MF056A FOLDING STAND 42PC1RV-ZJ CIS SET
3501900014C BOARD ASSEMBLY, D/T SPK STAND AP-42DC11 MF056A FOLDING STAND LGERS C/SKD
501 3301900095D PLATE ASSEMBLY, AV 3301900098A 3300900017D(PRESS) 42PC VCTP
3301900095Q PLATE ASSEMBLY, AV 3301900098A 3300900017H(PRESS) H3-M C/SKD
502 3301900094B PLATE ASSEMBLY, ASSY 3300900010D VCTP PDP PC SERIES COMMON 42PC1RV-ZJ CIS SET
3301900094G PLATE ASSEMBLY, ASSY 3300900010G H3 PDP PC SERIES EU, C/SKD
520 68719MMV88A PWB(PCB) ASSEMBLY, MAIN MAIN1 M.I PP61A 42PC1RV ZJ
68719MMW87A PWB(PCB) ASSEMBLY, MAIN MAIN1 M.I PP61A 42PC1RV ZJ CKD MANUAL INSERT FOR CKD (KETLLMP)
560 68719SMJ63A PWB(PCB) ASSEMBLY, SUB SUB M.I PP61A 42PC3RV Z LOCAL CLTR
68719SMM24A PWB(PCB) ASSEMBLY,SUB SUB M.I PP61A 42PC1RV Z CKD LOCAL (KETLLMP)
570 68719SMJ64A PWB(PCB) ASSEMBLY, SUB SUB M.I PP61A 42PC3RV Z PREAMP+LED
68719SMM25A PWB(PCB) ASSEMBLY,SUB SUB M.I PP61A 42PC1RV Z CKD PREAMP (KETLLMP)
580 6709900019A POWER SUPPLY ASSEMBLY 42INCH UNIFICATION PSU PDP LGIT PA61B 400W 42PB2D
600 68719SMJ74A PWB(PCB) ASSEMBLY,SUB SUB M.I PP61A 42PC3RV ZJ SIDEAV
68719SMM26A PWB(PCB) ASSEMBLY,SUB, SUB M.I PP61A 42PC1RV Z CKD SIDE AV (KETLLMP)
601 4811900021C BRACKET ASSEMBLY, SIDE AV 42PC1R-ZH PP62A CORTEZ-A, EU 42PC1RV-ZJ CIS SET
4811900021G BRACKET ASSEMBLY, SIDE AV 42PC1R-ZH PP62A SKD
602 48149V0003A SHIELD, SIDE AV 42PC1R
EXPLODED VIEW PARTS LIST
No. Part No. Descriptions
The components identified by mark is
critical for safety.
Replace only with part number specified.
