9
ENGLISH
_Index
Buttons
The image may be different ac
cording t
o the model.
Screen Buttons
Adjusts up and down.
Moves left and right.
Displays the current signal and mode.
Acc
esses the main menus, or saves your input and exits the menus.
Change the input signal.
T
urns the power on or off
.
NOTE
•
You can adjust the volume by using the r
emote contr
ol.
