LG 50PA4500 User Manual

106
ENG
ENGLISH
EXTERNAL CONTROL DEVICE SETUP
Transmission / Receiving Protocol
Transmission
[Command1][Command2][ ][Set ID][ ][Data][Cr]
[Command 1] : First command to control the TV.(j, k, m or x)
[Command 2] : Second command to control the TV.
[Set ID] : You can adjust the set ID to choose desired monitor ID number in option menu.
Adjustment range is 1 to 99. When selecting Set ID ‘0’, every connected set is controlled.
Set ID is indicated as decimal (1 to 99) on menu and as Hexa decimal (0x0 to 0x63) on
transmission/receiving protocol.
[DATA] : To transmit command data. Transmit ‘FF’ data to read status of command.
[Cr] : Carriage Return
ASCII code ‘0x0D’
[ ] : ASCII code ‘space (0x20)’
OK Acknowledgement
[Command2][ ][Set ID][ ][OK][Data][x]
* The set transmits ACK (acknowledgement) based on this format when receiving normal data. At this
time, if the data is data read mode, it indicates present status data. If the data is data write mode, it
returns the data of the PC computer.
Error Acknowledgement
[Command2][ ][Set ID][ ][NG][Data][x]
* The set transmits ACK (acknowledgement) based on this format when receiving abnormal data from
non-viable functions or communication errors.
Data 00: Illegal Code

LG 50PA4500 Specifications

General

3D	No
Depth	53.34 mm
Width	1168 mm
Height	703.6 mm
Weight	25830 g
HD type	Not supported
24p support	Yes
Pixel pitch	- mm
Smart modes	Cinema, Game, Standard, Vivid
Aspect ratio	4:3
HDMI version	1.3
Package depth	229.6 mm
Package width	1331 mm
Product color	Black
Package height	817.9 mm
Package weight	33790 g
RMS rated power	10 W
AC input voltage	100 - 240 V
Display diagonal	50 \
AC input frequency	50 - 60 Hz
Depth (with stand)	297.2 mm
Display brightness	- cd/m²
Display resolution	1024 x 768 pixels
Display technology	Plasma
Number of speakers	2
Height (with stand)	756.9 mm
Placement supported	Horizontal
Weight (with stand)	28210 g
Supported video modes	1080i, 1080p, 720p
USB 2.0 ports quantity	1
Audio formats supported	AAC, HE-AAC, LPCM, MP2, MP3, MS-ADPCM, WMA
Image formats supported	JPG
Number of OSD languages	4
S-Video inputs quantity	0
Video formats supported	DIVX
Contrast ratio (dynamic)	3000000:1
Contrast ratio (typical)	-
Equalizer bands quantity	5
Panel mounting interface	400 x 400 mm
Annual energy consumption	189.8 kWh
Display diagonal (metric)	126.7 cm
Screen format adjustments	4:3, 16:9
Analog signal format system	NTSC
Power consumption (standby)	0.2 W
Power consumption (typical)	130 W
Sustainability certificates	ENERGY STAR
Digital signal format system	ATSC
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
On Screen Display (OSD) languages	ENG, ESP, FRE, KOR
Consumer Electronics Control (CEC)	Anynet+
