LG 50PA4500 User Manual

56
ENG
ENGLISH
ENTERTAINMENT
Tips for using USB storage devices
 Only a USB storage device is recognizable.
 If the USB storage device is connected
through a USB hub, the device is not recog-
nizable.
 A USB storage device using an automatic
recognition program may not be recognized.
 A USB storage device which uses its own
driver may not be recognized.
 The recognition speed of a USB storage
device may depend on each device.
 Please do not turn off the TV or unplug the
USB device when the connected USB stor-
age device is working. When such device is
suddenly separated or unplugged, the stored
files or the USB storage device may be dam-
aged.
 Please do not connect the USB storage
device which was artificially maneuvered on
the PC. The device may cause the product to
malfunction or fail to be played. Never forget
to use only a USB storage device which has
normal music files, image files or movie files.
 Please use only a USB storage device which
was formatted as a FAT32 file system, NTFS
file system provided with the Windows op-
erating system. In case of a storage device
formatted as a different utility program which
is not supported by Windows, it may not be
recognized.
 Please connect power to a USB storage
device(over 0.5 A) which requires an external
power supply. If not, the device may not be
recognized.
 Please connect a USB storage device with
the cable offered by the device maker.
 Some USB storage devices may not be sup-
ported or operated smoothly.
 File alignment method of USB storage
device is similar to Window XP and filename
can recognize up to 100 English characters.
 Be sure to back up important files since data
stored in a USB memory device may be
damaged. We will not be responsible for any
data loss.
 If the USB HDD does not have an external
power source, the USB device may not be
detected. So be sure to connect the external
power source.
- Please use a power adaptor for an external
power source. We do not guarantee an USB
cable for an external power source.
Connecting USB storage devices
Connect USB storage devices such as a USB
flash memory, external hard drive to the TV and
use multimedia features (See “Browsing files”on
p.57).
Connect a USB flash memory or USB memory
card reader to the TV as shown on the following
illustration. The My media screen appears.
or
To disconnect a USB storage device,
make sure to end the connection properly to pre-
vent damages to the TV or files.
1 Press Q.MENU to access the quick menus.
2 Press the Navigation buttons to scroll to USB
Device and press OK.
3 Press the Navigation buttons to scroll to Eject
and press OK.
4 Disconnect the USB storage device only when
the message says that it is safe to remove.
 Do not turn the TV off or remove a USB
storage device while the USB storage
device is connected to the TV, as this
could result in loss of files or damage to
the USB storage device.
 Back up your files saved on a USB stor-
age device frequently, as you may lose
or damage the files and this may be not
covered by the warranty.
CAUTION
ENTERTAINMENT

LG 50PA4500 Specifications

General

3D	No
Depth	53.34 mm
Width	1168 mm
Height	703.6 mm
Weight	25830 g
HD type	Not supported
24p support	Yes
Pixel pitch	- mm
Smart modes	Cinema, Game, Standard, Vivid
Aspect ratio	4:3
HDMI version	1.3
Package depth	229.6 mm
Package width	1331 mm
Product color	Black
Package height	817.9 mm
Package weight	33790 g
RMS rated power	10 W
AC input voltage	100 - 240 V
Display diagonal	50 \
AC input frequency	50 - 60 Hz
Depth (with stand)	297.2 mm
Display brightness	- cd/m²
Display resolution	1024 x 768 pixels
Display technology	Plasma
Number of speakers	2
Height (with stand)	756.9 mm
Placement supported	Horizontal
Weight (with stand)	28210 g
Supported video modes	1080i, 1080p, 720p
USB 2.0 ports quantity	1
Audio formats supported	AAC, HE-AAC, LPCM, MP2, MP3, MS-ADPCM, WMA
Image formats supported	JPG
Number of OSD languages	4
S-Video inputs quantity	0
Video formats supported	DIVX
Contrast ratio (dynamic)	3000000:1
Contrast ratio (typical)	-
Equalizer bands quantity	5
Panel mounting interface	400 x 400 mm
Annual energy consumption	189.8 kWh
Display diagonal (metric)	126.7 cm
Screen format adjustments	4:3, 16:9
Analog signal format system	NTSC
Power consumption (standby)	0.2 W
Power consumption (typical)	130 W
Sustainability certificates	ENERGY STAR
Digital signal format system	ATSC
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
On Screen Display (OSD) languages	ENG, ESP, FRE, KOR
Consumer Electronics Control (CEC)	Anynet+
