34
ENGENGLISH
MAKING CONNECTIONS
Headphone connection
Transmits the headphone signal from the TV to an
external device. Connect the external device and the
TV with the headphone as shown.
(Only EG96**, EF95**)
(*Not Provided)
Headphone
NOTE
AUDIO menu items are disabled when con-
necting a headphone.
Optical Digital Audio Out is not available
when connecting a headphone.
Headphone impedance: 16 Ω
Max audio output of headphone: 0.627 mW
to 1.334 mW
Headphone jack size: 0.35 cm
USB connection
Connect a USB storage device such as a USB flash
memory, external hard drive or a USB memory card
reader to the TV and access the Smart Share menu
to use various multimedia files.
(Only EG96**, EG92**, EF95**)
HDD
(*Not Provided)
USB
HUB
(*Not Provided)
(*Not Provided)
