42
SPECIFICATIONS
(Only EG91**, EG92**, EG96**, EF95**)
Wireless module(LGSBW41) Specications
Wireless LAN Bluetooth
Standard IEEE 802.11a/b/g/n Standard Bluetooth Version 4.0
Frequency
Range
2400 to 2483.5 MHz
5150 to 5250 MHz
5725 to 5850 MHz(for Non EU)
Frequency
Range
2400 to 2483.5 MHz
Output Power
(Max.)
802.11a: 13 dBm
802.11b: 15 dBm
802.11g: 14 dBm
802.11n - 2.4 GHz: 16 dBm
802.11n - 5 GHz: 16 dBm
Output Power
(Max.)
10 dBm or Lower
Because band channel used by the country could be different, the user can not change or adjust the
operating frequency and this product is set for the regional frequency table.
This device should be installed and operated with minimum distance 20 cm between the device and
your body. And this phrase is for the general statement for consideration of user environment.
Product specications may be changed without prior notice due to upgrade of product functions.
For the power supply and power consumption, refer to the label attached to the product.
Thickness(T)
Depth(D)
MODELS
EG96**
55EG960T-TA
55EG960Y-TA
55EG965T-TA
55EG965Y-TA
65EG960T-TA
65EG960Y-TA
65EG965T-TA
65EG965Y-TA
Dimensions
With stand (mm)
(W x H x D)
1226 x 760 x 213 1447 x 884 x 237
Without stand (mm)
(W x H x T(D))
1226 x 719 x 50.1(87.8) 1447 x 842 x 50.1(102.5)
Weight
With stand (kg)
19 26.9
Without stand (kg)
15.3 21.7
Power requirement
AC 100-240 V~ 50 / 60 Hz
