ENGLISH
27
MAKING CONNECTIONS
OPTICAL
DIGITAL
AUDIO
OUT
H/P
Connecting a USB Device
Connect a USB storage device such as USB flash memory, external hard drive, or a USB memory card reader to the TV
and access the Smart Share menu to use various multimedia files.
1
2 3
USB IN
(*Not Provided)
Choose any USB input port to connect.
It does not matter which port you use.
USB HUB
USB
y
AUDIO menu options are disabled when using headphones.
y
When changing AV MODE with headphones connected, the change is applied to video but not to audio.
y
Optical Digital Audio Out is not available when headphones are connected.
y
Headphone impedance: 16
:
y
Max audio output: 10 mW to 15 mW
y
Headphone jack size: 0.35 cm (0.13 inches)
NOTE
Connecting Headphones
Listening to sound with headphones
y
Some USB Hubs may not work. If a USB device connected using a USB Hub is not detected, connect it to the
USB port on the TV directly.
NOTE
(*Not Provided)
Headphone
To Next Page
