3-643-63
Pin No. Desc. Standby Home Play
IC150 TPS65252
8 Vin1 12.324 12.17 12.14
9 LX1 5.06 5.1 5.1
12 LX2 0 1.243 1.243
13 Vin2 12.324 12.17 12.14
27 USB Vin 5.06 5.1 5.1
28 USB Vout 0 5.06 5.06
IC151 LM37102D
2 Vin 4.81 4.24 4.24
3 Vout 0 3.354 3.352
IC152 AZ1117BH-ADJTRE1
4 Vin 0 3.3 3.29
3 Vout 0 1.51 1.51
IC153 TLV71333DBVR
1 Vin 5.1 5.09 5.09
5 Vout 3.3 3.296 3.296
IC191 BD2242G
1 Vin 5.1 5.09 5.09
6 Vout 0 5.09 5.09
IC602 S34ML02G200TFI000
12 VCC 0 3.3 3.3
37 VCC 0 3.3 3.3
IC701 TPIC2050
3 P12V_3 12.3 12.2 12.16
24 A9P5 9.32 9.32 9.32
42 P12V_1 12.23 12.12 12.02
46 P12V_2 12.23 12.12 12.02
56 P5V_2 5.1 5.09 5.09
IC702 AZ1117BH-ADJTRE1
3 Vin 12.24 12.11 12.11
4 Vout 9.32 9.32 9.32
ICQ501 SBT3904
Emitter 0 0 0
Base 0.76 0 0
Collector 0.03 3.3 3.3
CIRCUIT VOLTAGE CHART
