Introduction
Connection Ports
1. AC IN
2. RJ45 Connector
3. HDMI Connector
4. * RGB OUT Connector
5. RGB IN 1 Connector
6. RGB IN 2 Connector
7. S-VIDEO In Connector
8. VIDEO Connector
9. RS232C Service Port
10. AUDIO IN Jack
11. AUDIO OUT Connector
12. Kensington
TM
Lock
LAN
2 3 4 5 8
1
6
7
This projector has a Kensington
Security System Connector on the
side panel. Connect the Kensington
Security System cable as below.
For the detailed installation and use of
the Kensington Security System, refer
to the user’s guide included with the
Kensington Security System set. And
for further information, contact
http://www.kensington.com, the
internet homepage of the Kensington
company that deals with expensive
electronic equipment such as notebook
PCs or projectors.
The Kensington Security System is an
optional item.
Kensington Security System
9 10
11
12
“*” for “RGB IN 1
Connector” only
