5 Appendix
Appendix 45
Appendix
5
General specifications
General
Power requirements Refer to the main label on the unit.
Power consumption Refer to the main label on the unit.
Dimensions (W x H x D) Approx. 450.0 mm x 167.0 mm x 332.0 mm
Operating temperature 5 °C to 35 °C
Operating humidity 5 % to 60 % RH
Inputs
Analog audio in (AUX IN 2) 3.5 Vrms, RCA jack (L, R)
Portable in (AUX IN 1) 1.8 Vrms (3.5 mm stereo jack)
Microphone (MIC 1/2) Sensitivity 20 mV, 6.3 mm jack x 2
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
System
Frequency Response 80 to 20,000 Hz
Signal-to-noise ratio More than 75 dB
Dynamic range More than 80 dB
Bus Power Supply (USB)
5 V 0 500 mA
Amplier (RMS Output power)
Total output 3,500 W RMS
HIGH 590 W RMS X 2 (6 Ω at 5 KHz, 30 % THD)
MID 590 W RMS X 2 (6 Ω at 1 KHz, 30 % THD)
LOW 570 W RMS X 2 (6 Ω at 70 Hz, 30 % THD)
y Design and specications are subject to change without notice.
