LG CM8450 User Manual

5 Appendix
Appendix
35
Appendix
5
General specifications
General
Power requirements Refer to the main label.
Power consumption
Refer to the main label.
Networked standby : 0.4 W
(If all network ports are activated.)
Dimensions (W x H x D) 450 mm x 160 mm x 355 mm
Net Weight (Approx.) 5.8 kg
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 60 %
Bus Power Supply 5 V
0
500 mA
Inputs
AUX IN 2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R)
PORT. IN 1.2 Vrms (3.5 Ø jack)
MIC 27 mV
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
CD
Frequency Response 40 to 20000 Hz
Signal-to-noise ratio 75 dB
Dynamic range 80 dB
Amplier
Total output 2 000 W
FRONT 500 W x 2 (6 Ω at 1 kHz)
REAR 500 W x 2 (6 Ω at 5 kHz)
THD 25 %
y
Design and specications are subject to change without notice.

LG CM8450 Specifications

General

Type	Home audio mini system
Cassette deck	-
Product color	Black, Red
Optical disc player	Yes
Number of optical discs	1 discs
Speaker type	4-way
RMS rated power	2500 W
Number of speakers	2
Number of subwoofers	1
Equalizer modes	Classic, Jazz, Pop, Rock
Programmable tracks	20
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Headphone connectivity	3.5mm / Bluetooth
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio formats supported	MP3, WMA
Power source	AC
Power consumption (standby)	0.5 W
Power consumption (typical)	250 W

Weight and Dimensions

Main unit weight	5800 g
Subwoofer weight	9600 g
Main unit dimensions (WxDxH)	450 x 355 x 160 mm
Subwoofer dimensions (WxDxH)	326 x 285 x 454 mm
