Getting Started 11
Getting Started
1
Rear panel
a Power cord
y Connect the power cord to wall outlet
directly if possible. Or when you use an
extension cable, it is highly recommended
to use an extension cable of 110 V / 15 A
or 230 V / 15 A, otherwise the unit may
not operate properly because of the lack of
power supply.
y Do not overload the extension cord with
excessive electrical load.
>
Caution
b SPEAKERS connector
c SPEAKER LIGHTING SYSTEM
d ANTENNA (FM)
e AUX IN (L/R)
r Disc tray
s MIC VOL (Microphone volume) / KEY CONTROL
- Controls microphone’s volume.
- Changes the key to suit your vocal range.
t PORT. (Portable) IN jack
u F (Function) / WIRELESS BOOM
- Selects the function and input source.
- Press and hold for 3 seconds to select Wireless
X-Boom Plus mode.
v Y SEARCH U (Skip/Search)
- Searches a folder or a file.
- Searches for a section within a track/file.
- Selects the radio stations.
a
bcde
