Option 2: Bottom Venting
1. Press the adapter duct onto the blower housing and secure it to the base of the dryer as shown.
LG DLEX4000 Ultra Large Front Load Electric Dryer-Installing the Side Vent Kit3
2. Insert the 4-inch (10.2 cm) elbow through the rear opening and press it onto the adapter duct. Be sure that the
male end of the elbow faces down through the hole in the bottom of the dryer. Secure it in place with duct tape.
Attach the cover plate to the back of the dryer with the included screw.
LG DLEX4000 Ultra Large Front Load Electric Dryer-Installing the Side Vent Kit5
Stacking the Dryer
Stacking Kit Installation
This stacking kit includes:
Two (2) side rails
One (1) front rail
Four (4) screws
