LG DLEX8100V User Manual

42
12
DISASSEMBLY INSTRUCTIONS
TOP PLATE①
2.
Push the top plate backward.
3.
Lift the top plate.
Unplug the dryer before servicing.
44
WARNING !
When you disassemble the top plate, be
sure to disconnect the dryer from its
electrical supply. Protect your hands and
arms from sharp edges when working.
To reduce the risk of Injury to persons
adhere to all industry recommended
safety procedures including the use of
long sleeved gloves and safety glasses.
WARNING !
THE DRYER TOP PLATE IS VERYLARGE
AND HEAVY. Fallure to follow
instructions can result in damage to the
dryer, property damage or Injury to persons.
1.
Remove 3 screws on the upper plate.
12
DISASSEMBLY INSTRUCTIONS

LG DLEX8100V Specifications

General

Type	Electric
Capacity	9.0 cu. ft.
Color	Graphite Steel
Drum Material	Stainless Steel
Energy Star Certified	Yes
Number of Drying Programs	14
Steam Technology	Yes
Smart Technology	LG ThinQ®
