LG F1480TDS User Manual

23
ow to use washer
H
Tub Clean is special cycle to clean the inside of the washing machine.
A higher water level is used in this cyle at higher spin speed. Perform this cycle regularly.
1. Remove any clothing or items from the
washer and close the door.
2. Open the dispenser drawer and add
Anti limescale (e.g. Calgon) to the Main
wash compartment.
3. Close the dispenser drawer slowly.
4.
Power On and then press and hold Rinse
and Temp. button for 3 seconds. then “ ”
will be displayed on the LED display.
5. Press the Start/Pause button to start.
6. After the cycle is complete, leave the door
open to allow the washer door opening,
flexible gasket and door glass to dry.
Do not add any detergent to the detergent compartments.
Excessive suds may generate and leak from the washer.
If there is a small child, be careful not to leave the door open for too long.
CAUTION
•
“Door Lock” - For safety reasons, the
door will lock while machine is in use and the
“Door Lock” icon will light up. You can safely
open the door after the “Door Lock” icon
turns off.
•
“Detecting” icon will light up, when
washing machining rotates slowly and
detects how much laundry is loaded in the
drum.
It will take a short time.
B
A
■ Tub Clean
■ Door Lock & Detecting

LG F1480TDS Specifications

General

Door hinge	-
Control type	Buttons, Rotary
Display type	LCD
Loading type	Front-load
Product color	Black, White
Viewing window	Yes
Appliance placement	Freestanding
Drying capacity	8 kg
Delay start (max)	19 h
Spin-drying class	A
Maximum spin speed	1400 RPM
Minimum spin speed	400 RPM
Noise level (spin)	69 dB
Noise level (wash)	54 dB
Energy consumption washing per cycle	- kWh
Water consumption washing & drying per cycle	56 L
Energy consumption washing & drying per cycle	1.04 kWh
Door opening angle	170 °

Weight and Dimensions

Depth	590 mm
Width	600 mm
Height	850 mm
Package weight	69000 g
