LG F1480TDS User Manual

9
nstallation
I
1. Unscrew the adapter ring plate and the 4
adapter retaining screws.
2. Push the adapter onto the end of the tap
so that the rubber seal forms a watertight
connection. Tighten the adapter ring plate
and the 4 screws.
3. Push the water supply hose vertically
upwards so that the rubber packing within
in the hose can adhere completely to the
tap and then tighten it by screwing it to
the right.
• Water supply pressure must be between 100 kPa and 1000 kPa (1.0 ~ 10.0 kgf / cm
2
)
• Do not strip or crossthread when connecting Inlet hose to the valve.
• If the water supply pressure is more than 1000 kPa, a decompression device should be
installed.
• Periodically check the condition of the hose and replace the hose if necessary.
Type-1: Connecting Screw-type hose to tap with thread
Type-2: Connecting Screw-type hose to tap without thread
• Make sure that there are no kinks on the
hose and that they are not crushed.
When your washer has two valves.
• The Inlet hose which has red connector is
for the hot water tap.
• If the washer has two valves, the energy is
saved by using hot valve.
1. Screw the hose connector onto water
supply tap.
■ To connect water supply hose
■ Connecting hose to water tap
Two rubber seals are supplied with
the water inlet hoses.
They are used for preventing water
leaks. Make sure the connection to
taps is sufficiently tight.
Hose
connector
Upper
connector
Rubber
packing
Plate
Water supply
hose
Fixing screw
Rubber
seal

LG F1480TDS Specifications

General

Door hinge	-
Control type	Buttons, Rotary
Display type	LCD
Loading type	Front-load
Product color	Black, White
Viewing window	Yes
Appliance placement	Freestanding
Drying capacity	8 kg
Delay start (max)	19 h
Spin-drying class	A
Maximum spin speed	1400 RPM
Minimum spin speed	400 RPM
Noise level (spin)	69 dB
Noise level (wash)	54 dB
Energy consumption washing per cycle	- kWh
Water consumption washing & drying per cycle	56 L
Energy consumption washing & drying per cycle	1.04 kWh
Door opening angle	170 °

Weight and Dimensions

Depth	590 mm
Width	600 mm
Height	850 mm
Package weight	69000 g
