LG F1480TDS User Manual

6
nstallation
I
■ Removing packing
Base Packing
Washer
Spanner
1. Remove the cardboard box and
styrofoam packing.
2. Lift the washing machine and remove
the base packing.
3. Remove the tape securing the power
supply cord and drain hose.
4. Remove the inlet hose from the drum.
1. Unscrew the 4 bolts with
the spanner supplied.
2. Take out the 4 bolts along with the
rubber bungs by slightly twisting the
bung.
3. Close the holes with the caps supplied.
Keep the transit bolts for future
use.
To prevent internal damage during transport, the 4 special bolts are locked.
Before operating the washer, remove the bolts along with the rubber bungs.
If they are not removed, it may cause heavy vibration, noise and malfunction.
■ Removing transit bolts
Keep the spanner in base
packing for leveling.
Transit bolt
Packaging material (e.g. Films, Styrofoam) can be dangerous for children.
There is a risk of suffocation !
Keep all packaging well away from children.
Warning

LG F1480TDS Specifications

General

Door hinge	-
Control type	Buttons, Rotary
Display type	LCD
Loading type	Front-load
Product color	Black, White
Viewing window	Yes
Appliance placement	Freestanding
Drying capacity	8 kg
Delay start (max)	19 h
Spin-drying class	A
Maximum spin speed	1400 RPM
Minimum spin speed	400 RPM
Noise level (spin)	69 dB
Noise level (wash)	54 dB
Energy consumption washing per cycle	- kWh
Water consumption washing & drying per cycle	56 L
Energy consumption washing & drying per cycle	1.04 kWh
Door opening angle	170 °

Weight and Dimensions

Depth	590 mm
Width	600 mm
Height	850 mm
Package weight	69000 g
