1. Remove the cardboard box and
styrofoam packing.
2. Lift the washing machine and remove
the base packing. This will require 2 or
more people or a lifting device.
3. Remove the tape securing the power
supply cord and drain hose.
4. Remove the inlet hoses from the drum.
1. Unscrew the 4 bolts with the spanner
supplied.
2. Take out the 4 bolts along with the
rubber bungs by slightly twisting the
bung.
3. Close the holes with the caps supplied.
To prevent internal damage during transport, the 4 special bolts are locked.
Before operating the washer, remove the bolts along with the rubber bungs.
If they are not removed, it may cause heavy vibration, noise and malfunction.
■ Removing transit bolts
Transit bolt
• Keep the spanner provided for
future use.
• Packaging material (e.g. Films, Styrofoam) can be dangerous for children.
There is a risk of suffocation ! Keep all packaging well away from children.
• Keep the transit bolts for future use.
NOTE
NOTE
WARNING
