12
INSTALLATION
Installation Place
Requirements
Before installing the appliance, check the
following information to make sure that
the appliance should be installed in a
correct place.
Installation Location
• This appliance must be installed on
firm flooring to minimize vibration
during the spin cycle. Concrete
flooring is best, being far less prone to
vibration during the spin cycle than
wooden floorboards or a carpeted
surface.
• If it is impossible to avoid positioning
the appliance next to a gas cooker or
coal burning stove, an insulation (850 X
600 mm) covered with aluminum fo
il
on the side facing the cooker or stove
must be inserted between the two
appliances.
• Ensure that when the appliance is
installed, it is easily accessible for an
engineer in the event of a breakdown.
• When installing the appliance, adjust
all four feet using the transit bolt
spanner provided to ensure the
appliance is stable.
Floor Installation
To ensure sufficient clearance for water
inlet hoses, drain hose and airflow, allow
minimum clearances of at least 20 mm at
the sides and 100 mm behind the
appliance. Be sure to allow for wall, door,
or floor moldings that may increase the
required clearances.
WARNING
• This appliance must only be used for
domestic household purposes and
should not be used in mo
bile
applications.
NOTE
• Never try to level any uneven floor by
putting pieces of wood, cardboard or
similar materials under the appliance.
Wooden Floors (Suspended
Floors)
When installing the appliance on
wooden floors, use rubber cups to
reduce excessive vibration and
unbalance. Timber or suspended type
flooring may contribute to excessive
A 100 mm
B 5 mm
C 20 mm
A C
B
C
global_main.book.book Page 12 Monday, August 17, 2020 8:48 AM

LG FAV309WNE Specifications

General

No rinse	No
Drum capacity	9 kg
Menu languages	English
Delay start (max)	19 h
Residual moisture	53 %
Spin-drying class	B
Maximum spin speed	1400 RPM
Minimum spin speed	400 RPM
Noise level (spin)	73 dB
Noise level (wash)	54 dB
Delayed start timer	Yes
Left-on mode duration	12 min
Number of rinse selections	2
Number of washing programs	14
Maximum washing temperature	95 °C
Cycle time (quick washing program)	14 min
Door color	Black, White
Door hinge	Left
Motor type	Beltless
Water fill	Cold
Cord length	1.9 m
Control type	Rotary, Touch
Display type	LED
Loading type	Front-load
Drum material	Stainless steel
Product color	White
Country of origin	China
Custom panel-ready	-
Appliance placement	Freestanding
Dispenser tray type	3-way
Feet adjustment	20 mm
Current	13 A
Power plug type	Type G
AC input voltage	220 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (standby)	0.5 W
Water consumption per cycle	50 L
Energy consumption washing per cycle	0.571 kWh
Package width	660 mm
Package height	890 mm
Package weight	Weight of the packaged product in gram.
Category	Washing machine
Washing class	A
Power requirements	Mains
Quantity per pack	1 pc(s)
Proper shipping name	FAV309WNE.ABWQPUK
UK Trade Tariff code	8450119000
Quantity per pallet layer	2 pc(s)
Quantity per intermodal container (20ft)	22 pc(s)
Quantity per intermodal container (40ft)	44 pc(s)
Quantity per intermodal container (40ft, HC)	180 pc(s)

Weight and Dimensions

Depth	565 mm
Width	600 mm
Height	850 mm
Weight	66000 g
Gross weight	70000 g
Door diameter	510 mm
Depth with door open	1000 mm
Door opening diameter	300 mm
Installation compartment depth	665 mm
Installation compartment width	640 mm
Installation compartment height	855 mm
