INSTALLATION

NOTE

• It must not ‘Seesaw’ across corners

under the load.

• Do not let the feet of the appliance get

wet. Failure to do so may cause

vibration or noise.

Using Anti-Slip Sheets

This feature may vary depending on the

model purchased.

If you install the appliance on a slippery

surface, it may move because of

excessive vibration. Incorrect levelling

may cause malfunction through noise

and vibration. If this occurs, install the

anti-slip sheets under the levelling feet

and adjust the level.

Clean the floor to attach the anti-slip

sheets.

• Use a dry rag to remove and clean

foreign objects and moisture. If

moisture remains, the anti-slip

sheets may slip.

Adjust the level after placing the

appliance in the installation area.

Place the adhesive side

of the anti-

slip sheets on the floor.

• The most effective way is to install

the anti-slip sheets under the front

feet. If it is difficult to place the

sheets un

der the front feet of the

appliance, attach them under the

rear feet.

Put the appliance on the anti-slip

sheets.

• Do not attach the adhesive side

of anti-sli

p sheets to the feet of the

appliance.

NOTE

• Additional anti-slip sheets are available

at LG Electronics service centre.

Connecting the Water

Supply Hose

Note for Connection

• Water pressure must be between

kPa

and

800 kPa

(0.5‒8.0 kgf/cm²). If

the water pressure is more than

800

kPa

, a decompression device should

be installed.

• Periodically check the condition of the

water supply hose and replace th

water supply hose if necessary.

NOTE

• Do not overtighten the water supply

hose or use mechanical devices to

tighten onto the inlet valves.

global_main.book.book Page 16 Monday, August 17, 2020 8:48 AM

Questions and Answers:

Need help?

Do you have a question about the LG FAV309WNE and is the answer not in the manual?

LG FAV309WNE Specifications

General

No rinse	No
Drum capacity	9 kg
Menu languages	English
Delay start (max)	19 h
Residual moisture	53 %
Spin-drying class	B
Maximum spin speed	1400 RPM
Minimum spin speed	400 RPM
Noise level (spin)	73 dB
Noise level (wash)	54 dB
Delayed start timer	Yes
Left-on mode duration	12 min
Number of rinse selections	2
Number of washing programs	14
Maximum washing temperature	95 °C
Cycle time (quick washing program)	14 min
Door color	Black, White
Door hinge	Left
Motor type	Beltless
Water fill	Cold
Cord length	1.9 m
Control type	Rotary, Touch
Display type	LED
Loading type	Front-load
Drum material	Stainless steel
Product color	White
Country of origin	China
Custom panel-ready	-
Appliance placement	Freestanding
Dispenser tray type	3-way
Feet adjustment	20 mm
Current	13 A
Power plug type	Type G
AC input voltage	220 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (standby)	0.5 W
Water consumption per cycle	50 L
Energy consumption washing per cycle	0.571 kWh
Package width	660 mm
Package height	890 mm
Package weight	Weight of the packaged product in gram.
Category	Washing machine
Washing class	A
Power requirements	Mains
Quantity per pack	1 pc(s)
Proper shipping name	FAV309WNE.ABWQPUK
UK Trade Tariff code	8450119000
Quantity per pallet layer	2 pc(s)
Quantity per intermodal container (20ft)	22 pc(s)
Quantity per intermodal container (40ft)	44 pc(s)
Quantity per intermodal container (40ft, HC)	180 pc(s)

Weight and Dimensions

Depth	565 mm
Width	600 mm
Height	850 mm
Weight	66000 g
Gross weight	70000 g
Door diameter	510 mm
Depth with door open	1000 mm
Door opening diameter	300 mm
Installation compartment depth	665 mm
Installation compartment width	640 mm
Installation compartment height	855 mm
