Copyright © 2010 LG Electronics. Inc. All right reserved. - 17 - LGE Internal Use Only
Only for training and service purposes
1) Turn off the power switch at the front side of the display.
2) Wait for about 5 seconds and press MODE, POWER switch with 1 second interval, press MENU.
3) The SVC OSD menu contains additional menus that the User OSD menu as described below.
a) CLEAA ETI: NO
b) Auto Color: NO
c) AGING: Select Aging mode (on/off).
d) PANEL: Used panel type
e) NVRAM INIT: NO
f) R/G/B-9300K: Allows you to set the R/G/B-9300K value manually.
g) R/G/B-6500K: Allows you to set the R/G/B-6500K value manually.
h) R/G/B-Offset: Allows you to set the R/G/B-Offset value manually. (Analog Only)
i) R/G/B-Gain: Allows you to set the R/G/B-Gain value manually. (Analog Only)
e) R/G/B-sRGB: Allows you to set the R/G/B- sRGB value manually.
Figure 1 Cable Connection for Micom uploading
SERVICE MODE
Connect to
the PC
Connect to
the monitor
To Next Page
