LG LG-500 User Manual

- 28 -
5.2.4 Melody Trouble
Melody is not heard
Check the connectivity
of speaker.
The connection
is OK
Check the level of U605,
PIN5(VCC3V).
The level is
high(3V)
Connect the speaker
to the phone properly.
Check whether the
melody signal(a few hundreds
mV) is out from the U603.
12 or U603.11.
Replace the LDO(U605)
Replace the Melody IC,
(U603).
END
YES
YES
YES
NO
NO
NO
