5.2.7 Vibrator is not working
5. Data Kit & Test Method
START
Check/Replace
Vibrator
Reassemble J701
Check/Replace the R732
Check/Replace the T702
Check/Replace the R730, L701, C701
In the Test mode, select
‘Baseband Test’ then
select ‘Vibrator Mode’
J701 is well
connected to the
Vibrator
R732 Voltage
Level is High
(approx.3V)
T702 Collector
Voltage Level is High
(Approx.3V)
Voltage level
of R730, L701, C701
are Low
YES
YES
YES
YES
NO
NO
NO
NO
NOTE : To get to the Test mode, press
2945 → #, then hold down * key.
