3. TROUBLE SHOOTING
- 166 -
Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
< Gyro/Accel Sensor Circuit >
< Main board _Bottom >
U11001 (MPU6515)
Gyro / Accel Sensor
+1V8_VREG_LVS1
C11003
100n
C11014
10n
C11015
0.1u
0.1u
C11013
+1V8_VREG_LVS1
U11001
EAN62826901
MPU-6515
16
22
19
20
21
23
24
18 17
9
8
10
7
11
6
12
5
13
4
14
3
15
2 1
NC1
NC2
NC8
NC3
NC7
NC4
VDD
NC5
INT
NC6
FSYNC
AUX_CL
REGOUT
VDDIO
SDO/AD0
NC10
GND
SDA/SDI
SCL/SCLK
AUX_DA
RESV2
RESV1
NCS
NC9
DNI
R11070
DNI
R11071
+1V8_VREG_LVS1
+1V8_VREG_LVS1
SENSOR1_I2C_SCL
SENSOR1_I2C_SDA
MPU6515_INT
COMPASS_OUT_I2C_SDA
COMPASS_OUT_I2C_SCL
revA->revB(13004.29)
For informing DMP Data event to AP
U11001
