LG-D821 Product SPEC
27
17) RSSI indicator (Based on Cell power) :
Specification
Unit
LTE WCDMA GSM CDMA
BAR 4->3 -85dBm±3dBm -88dBm±3dBm -90dBm±3dBm -76dBm±3dBm
Antenna
BAR
BAR 3->2 -95dBm±3dBm -96dBm±3dBm -98dBm±3dBm -86dBm±3dBm
BAR 2->1 -105dBm±3dBm -102dBm±3dBm -104dBm±3dBm -96dBm±3dBm
BAR 1->0 -115dBm±3dBm -106dBm±3dBm -108dBm±3dBm
-
101dBm±3dBm
1) WCDMA setting : Uplink ParametersMaximum Uplink Transmit Power Level(=24dBm)
2)After cell power change, at least 10sec delay is necessary before RSSI measurement.(RSSI stability)
18) Battery indicator
Battery Bar Specification Battery Bar Specification
Bar 20(Full) 98% above Bar 9 -> Bar 8 43% -> 42%
Bar 20 -> Bar 19 98% -> 97% Bar 8 -> Bar 7 38% -> 37%
Bar 19 -> Bar 18 93% -> 92% Bar 7 -> Bar 6 33% -> 32%
Bar 18 -> Bar 17 88% -> 87% Bar 6 -> Bar 5 28% -> 27%
Bar 17 -> Bar 16 83% -> 82% Bar 5 -> Bar 4 23% -> 22%
Bar 16 -> Bar 15 78% -> 77% Bar 4 -> Bar 3 18% -> 17%
Bar 15 -> Bar 14 73% -> 72% Bar 3 -> Bar 2 13% -> 12%
Bar 14 -> Bar 13 68% -> 67% Bar 2 -> Bar 1 8% -> 7%
Bar 13 -> Bar 12 63% -> 62% Bar 1 -> Bar 0 3% -> 2%
Bar 12 -> Bar 11 58% -> 57% Power off 1% below
Bar 11 -> Bar 10 53% -> 52% Low battery pop-up 14% ,4%
Bar 10 -> Bar 9 48% -> 47%
LG-D821 Product SPEC
27
17) RSSI indicator (Based on Cell power) :
Specification
Unit
LTE WCDMA GSM CDMA
BAR 4->3 -85dBm±3dBm -88dBm±3dBm -90dBm±3dBm -76dBm±3dBm
Antenna
BAR
BAR 3->2 -95dBm±3dBm -96dBm±3dBm -98dBm±3dBm -86dBm±3dBm
BAR 2->1 -105dBm±3dBm -102dBm±3dBm -104dBm±3dBm -96dBm±3dBm
BAR 1->0 -115dBm±3dBm -106dBm±3dBm -108dBm±3dBm
-
101dBm±3dBm
1) WCDMA setting : Uplink ParametersMaximum Uplink Transmit Power Level(=24dBm)
2)After cell power change, at least 10sec delay is necessary before RSSI measurement.(RSSI stability)
18) Battery indicator
Battery Bar Specification Battery Bar Specification
Bar 20(Full) 98% above Bar 9 -> Bar 8 43% -> 42%
Bar 20 -> Bar 19 98% -> 97% Bar 8 -> Bar 7 38% -> 37%
Bar 19 -> Bar 18 93% -> 92% Bar 7 -> Bar 6 33% -> 32%
Bar 18 -> Bar 17 88% -> 87% Bar 6 -> Bar 5 28% -> 27%
Bar 17 -> Bar 16 83% -> 82% Bar 5 -> Bar 4 23% -> 22%
Bar 16 -> Bar 15 78% -> 77% Bar 4 -> Bar 3 18% -> 17%
Bar 15 -> Bar 14 73% -> 72% Bar 3 -> Bar 2 13% -> 12%
Bar 14 -> Bar 13 68% -> 67% Bar 2 -> Bar 1 8% -> 7%
Bar 13 -> Bar 12 63% -> 62% Bar 1 -> Bar 0 3% -> 2%
Bar 12 -> Bar 11 58% -> 57% Power off 1% below
Bar 11 -> Bar 10 53% -> 52% Low battery pop-up 14% ,4%
Bar 10 -> Bar 9 48% -> 47%
18) RSSI indicator (Based on Cell power) :
19) Battery indicator
1) WCDMA setting : Uplink Parameters-> Maximum Uplink Transmit Power Level(=24dBm)
2) After cell power change, at least 10sec delay is necessary before RSSI measurement.(RSSI stability)
