ROOF-VENTED INSTALLATION:
1. Remove one blower unit mounting screw and
one or several blower plate mounting screw(s).
Remove the blower plate from cabinet. See
Figure 19.
2. Carefully lift the blower unit out of the microwave
oven.
3. Rotate blower unit 90 so the exhaust ports face
the top of the cabinet. See Figure 20.
4. Place blower unit back into microwave oven.
5. Use side cutter or tin snips to cut and remove knockouts
"A" from blower plate. Discard knockouts. Be careful not
to distort the plate. See Figure 21.
6. Reattach blower plate to microwave oven.
Attach with the one blower unit mounting screw and then
the two blower plate mounting screws. See Figure 22.
