NOTE
1) Gently insert the tube until only one
line shows on the tube.
(Correct)
(Incorrect)
2) Pull the tube to make sure that the
tube is tightly fastened.
Collet
Tube
Insert Line
Removing the CustomChill™ Drawer
1
Pull the drawer open to full extension.
Remove the basket by lifting the basket
from the rail system.
3
Hold both sides of the door and lift it to
remove it from the rail system.
2
Disconnect the wire harness connection
at the end of the right rail by pressing on
the tabs on either side. It may help to use
a small, flat-blade screwdriver to apply
pressure to the ends of the tabs on either
side.
NOTE
Before removing the CustomChill™
drawer, it must be disconnected from
the temperature control.
To Next Page
