14
9. CONNECT THE TUBING TO THE
REFRIGERATOR
2. Place the compression nut and ferrule (sleeve) onto
the end of the tubing (See figure 1).
3. Insert the end of the tubing into the connection as
far as possible. While holding the tubing, tighten the
Fasten the tubing into the tubing clamp attached to the
back of the refrigerator.
First, loosen the screw fastening the clamp. Next,
insert the tubing in the groove. Finally, re-fasten the
screw.
10. PLUG IN THE REFRIGERATOR
Arrange the coil of tubing so
that it does not vibrate against
the back of the refrigerator or
against the wall. Push the
refrigerator back to the wall.
11. START THE ICEMAKER
Set the icemaker power switch to the (ON) I position.
The icemaker will not begin to operate until it
reaches its operating temperature of 15 °F (-9 °C)
or below. It if will then begin operation automatically
the icemaker position.power switch is in the (ON) I
fitting (Part A).
NOTES:
Before making the connection to the refrigerator, be
sure the refrigerator power cord is not plugged into
the wall outlet.
If your refrigerator does not have a water filter,
we recommend installing one. If your water supply
has sand or particles that could clog the screen of
the refrigerator’s water valve, install the filter in the
water line near the refrigerator.
1. Remove the plastic flexible cap from the refrigerator
connection.
Do not use old hoses; only use new hoses provided
CAUTION: Check to make sure that leaks are not
occurring in the water line.
8. FLUSH OUT THE TUBING
Turn the main water supply on
and flush out the tubing until the
water is clear.
Shut the water off at the water
valve after about one quart of
water has been flushed through
the tubing.
REFRIGERATOR INSTALLATION
by the manufacturer.
¼” (6.35 mm) Tubing
Refrigerator
Connection
Tubing Clamp
¼” (6.35 mm)
Compression
Nut
Ferrule
(Sleeve)
2
1
Part A
Back of refrigerator
Figure 1
