LG LSW200B User Manual

6
5
How to level the Display
After installing the display, check to make sure it is level. The wall mount has two
screws that make minor adjustments to the level.
6
Cable arrangement and set protection cushion
- Arrange the cables as shown in the picture. Use some type of cable banding device to hold all the cables together.
- Attach the set protection cushion to mitigate the impact between the wall and the set when adjusting the angle. Attach the
set protection cushion as shown in the picture.
<LSW200B/LSW200BG/LSW200BX/LSW200BXG> <LSW400B/LSW400BG/LSW400BX/LSW400BXG>
Product specification
Model Name
LSW200B
LSW200BG
LSW200BX
LSW200BXG
LSW400B
LSW400BG
LSW400BX
LSW400BXG
Width (mm)
281 281 440 440
Height (mm)
234 234 450 450
Depth (mm)
14 31 14 30.5
Weight (kg)
1.5 1.5 3.4 3.4
Wall Mount VESA
Specification
200 X 200 200 X 200 400 x 400 400 x 400
Max.UL Load
Capacity (kg)
40 40 50 50
Model Name
LSW200B
LSW200BG
LSW200BX
LSW200BXG
LSW400B
LSW400BG
LSW400BX
LSW400BXG
Width (mm)
460 460 460 460
Height (mm)
234 234 450 450
Depth (mm)
20 37 20 36.5
Weight (kg)
3.2 3.2 5.6 5.6
Wall Mount VESA
Specification
200 X 200 200 X 200 400 x 400 400 x 400
Max.UL Load
Capacity (kg)
40 40 50 50
<With the bracket removed.> <With the bracket attached.>
LSW200B/LSW200BG/LSW200BX/LSW200BXG : ± 5mm(Leveling)
LSW400B/LSW400BG/LSW400BX/LSW400BXG : ± 10mm(Leveling)
<
° ~ °± °
° ~ °± °
During the locking of the hanger bracket, insert the cable into the
groove at the bottom of the hanger bracket before the assembly.

LG LSW200B Specifications

General

Brand	LG
Model	LSW200B
Category	TV Mount
Language	English
