APPENDIX
APPENDIX
■ The specifications shown above may be changed without prior notice for quality improvement.
PRODUCT SPECIFICATIONS
M2080D / M2080DF / M2080DB / M2080DN
LCD Panel
Screen Type
508.5 mm Wide (20.0 inch) TFT (Thin Film Transistor)
LCD (Liquid Crystal Display) Panel
Visible diagonal size: 508.5 mm
Pixel Pitch
0.2766 mm (H) x 0.2766 mm (V)
Video Signal
Max. Resolution
1600 x 900 @ 60 Hz
Recommended Resolution
1600 x 900 @ 60 Hz
Horizontal Frequency
30 kHz to 65 kHz
Vertical Frequency
56 Hz to 75 Hz
Synchronization Type
Separate Sync, Digital
Input Connector
TV, D-Sub Analog, SCART, PC Audio In, component, HDMI*2, CVBS
Power
Rated Voltage
19 V 2.0 A
Power Consumption
On Mode 32 W (typ.)
Off Mode ≤ 1 W
AC/DC Adapter Manufacturer: LITE-ON, Model PA-1650-68
Tilt Tilt Range
-5° to 10°
Dimensions (Width x Height x Depth)
Weight
M2080D
476.4 mm x 376.1 mm x 193.8 mm (18.75 inch x 14.81 inch x 7.62 inch)
3.5 kg ( 7.12 lb)
M2080DF
476.4 mm x 387.8 mm x 193.9 mm (18.75 inch x 15.26 inch x 7.63 inch)
3.7 kg ( 8.16 lb)
M2080DB
476.4 mm x 389.4 mm x 194.4 mm (18.75 inch x 15.33 inch x 7.65 inch)
3.5 kg ( 7.12 lb)
M2080DN
476.4 mm x 310.5 mm x 56.1 mm (18.75 inch x 12.22 inch x 2.21 inch)
2.7 kg ( 5.95 lb)
Environmental
conditions
Operating Temperature
Operating Humidity
10 °C to 35 °C
20 % to 80 %
-10 °C to 60 °C
5 % to 90 %
Storage Temperature
Storage Humidity

LG M2380D Specifications

General

Aspect ratio	16:9
Display diagonal	23 \
Contrast ratio (dynamic)	5000000:1
Display brightness (typical)	250 cd/m²
USB hub version	2.0
DVI-I ports quantity	0
Built-in speaker(s)	-
Built-in subwoofer	Yes
Power consumption (standby)	0.28 W
Power consumption (typical)	37.8 W
Product color	Black
Panel mounting interface	- mm

Weight and Dimensions

Depth (without stand)	54 mm
Width (without stand)	509.6 mm
Height (without stand)	330.5 mm
Weight (without stand)	3800 g
