8800
OPTION SETTING
The Audio function allows selection of a preferred language.
If audio data in a selected language is not broadcast, the default language audio will be played.
Use the Subtitle function when two or more subtitle languages are broadcast. If subtitle data in a selected lan-
guage is not broadcast, the default language subtitle will be displayed.
When the languages you selected as the primary for Audio Language and Subtitle Language are not support-
ed, you can select language in secondary category.
LANGUAGE SELECTION (IN DIGITAL MODE ONLY)
Select
OOPPTTIIOONN
.
2
Select
AAuuddiioo LLaanngguuaaggee
,
SSuubbttiittllee
LLaanngguuaaggee
.
1
3
Select your desired language.
4
Save.
MENU
OK
OK
OK
Select
OOPPTTIIOONN
.
2
Select
HHaarrdd ooff
HHeeaarriinngg(( ))
.
1
3
Select
OO nn
or
OOffff
.
MENU
OK
OK
Press the MENU or EXIT button to close the menu window.
Press the RETURN button to move to the previous menu screen.
< Audio Language Selection >
G
When two or more audio languages are broadcast, you can
select the audio language.
GG
When Dolby Digital or Dolby Digital PLUS received, you can-
not select the L+R, L+L or R+R.
- The audio/subtitles can be displayed in a simpler form with 1 to 3 characters broadcast by the service provider.
- When you select supplementary Audio (Audio for “Visual/Hearing Impaired”) it may output a part of the Main audio.
Audio Language OSD Information
< Subtitle Language Selection >
G
When two or more subtitle languages are broadcast, you
can select the subtitle language with the SUBTITLE button
on the remote control.
G
Press the
D E
button to select a subtitle language.
Subtitle Language OSD Information
Status
Not Available
Teletext Subtitle
Subtitle for “Hard of Hearing”
Display
N.A
Status
Not Available
MPEG Audio
Dolby Digital Audio
Audio for “Visual Impaired”
Audio for “Hearing Impaired”
Dolby Digital Plus Audio
AAC Audio
Display
N.A
Select
AAuuddiioo
Select an audio language.
Select L+R, L+L or R+R.
1
Q. MENU
23
OK

Table of Contents

Other manuals for LG M2762D

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the LG M2762D and is the answer not in the manual?

LG M2762D Specifications

General IconGeneral
Pixel pitch0.3114 x 0.3114 mm
Aspect ratio16:9
Display diagonal27 \
Separate H/V syncYes
Vertical scan range56 - 75 Hz
Horizontal scan range30 - 83 kHz
Viewable size diagonal584.2 mm
Viewing angle, vertical160 °
Contrast ratio (dynamic)50000:1
Contrast ratio (typical)1000:1
Viewing angle, horizontal170 °
Display brightness (typical)300 cd/m²
Bandwidth0.135 GHz
Display viewable area (HxV)597.7 x 336.2 mm
Display resolution at frequency1920 x 1080 @ 60 Hz
USB hub version2.0
RMS rated power6 W
CertificationTÜV-Typ, CE, UL, CSA, SEMKO, FCC-B
Product colorBlack
Market positioning-
Compliance industry standardsDDC 2B
LED indicatorsStand-by
Tilt angle range-5 - 15 °
Panel mounting interface100 x 100 mm
Power consumption (standby)1 W
Power consumption (typical)120 W
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth (without stand)210 mm
Width (without stand)654.1 mm
Height (without stand)494.6 mm
Weight (without stand)8920 g
