LG MAX221UB Service Manual

1-6
HOW TO SETTING THE OPTION CODE
1. Option Table
Option Codes for Media Receiver products of 2012 will be defi ned as below
* OPTION TABLE
INDEX AREA RDS OPTION CODE SUFFIX
1 EU SUPPORT 111
EDEULL*
EDZALL*
EESPLL*
EHUNLL*
EMARLL*
ESWELL*
ETUREL*
EZAFLL*
2 EU SUPPORT 112 ERUSLL*
3 EU PS_RT_ONLY 121
EINDLL*
EIRNJL*
EISRRL*
ENGALL*
ESAUBL*
YEGYIL*
4 S.America PS_RT_ONLY 221
ECHLLL*
ECOLLL*
EPANLL*
PBRALL*
YMEXCL*
The option code is comprised of 3 digits and each digit has a range 1~6.
In the 2012, Media Receiver Product has totally four option codes from entire suffi xes.
2. Operation
1. Entering Option Setting Function
1) Power off on the radio source.
2) Push and hold the SRC(PWR) Key for 5 seconds, then It goes to the version display mode.
3) Push BAND Key until the LCD displays “OPTION(OPTN) XYZ”.
(The XYZ means the Option Code)
2. How to change the option code
1) The Input mode can be set by press the volume knob, the fi rst digit will be blinking until the
new code is set.
2) The number what you want to input could be selected by spinning the volume knob clockwise or
counterclockwise.
And then, if you push the volume knob, the selected number will be changed and the focus is moving
to the next.
You can also input the new option code of 1~6 by using preset keys if they are on the front panel.
3) If the new option code is acceptable, “SUCCESS XYZ” will be displayed on the LCD, and then it’ll reset
soon automatically.
4) If the new option code is not acceptable, “CODE ERR” will be displayed on the LCD.
To retry to change the option code, push the volume knob again.
