n Heating Mode Operation
The unit will operate according to the setting by the remote controller and the operation diagram is shown as following.
n Hot-start Control
• The indoor fan does no rotate until the evaporator piping temperature will be reached to 25°C(76°F).
• The operation diagram is as following.
35°C(94°F)
30°C(86°F)
27°C(80°F)
25°C(76°F)
22°C(72°F)
Pipe
temperature
OFF
Indoor fan
speed
LO
LOW
LOW
SELECTED
FAN
LOW
LOLOW
COMP ON
Operation Detail
Thermal OFF ON
OFF ON
ON
ON
Outdoor fan
Indoor fan
4 Way ON
Room
Temperature
Thermal Off
Thermal On
Indoor pipe
Temperature
33°C(92°F)
25°C(76°F)
20°C(68°F)
36°C(96°F)
Minimum
3min
Setting
fan
speed
Setting
fan
speed
Setting
fan
speed
Stop Low Stop StopLow LowLow Low
Thermal ON Thermal OFF
Indoor Unit mode ST+2 ST+4
2TH To be selected lower temperature To be selected lower temperature
(Remo.+Indoor) contrast Indoor Unit and Remo. contrast Indoor Unit and Remo.
Remo. mode ST+0 ST+2
