LG Multi V Installation Manual

16 Outdoor Unit
Installation Space
Installation Space
Individual Installation
n During the installation of the unit, consider service, inlet, and outlet and acquire the minimum space
as shown in the figures below.
A E
B
D
A
C
B
D
E
C
A E
B
F
C
D
A E
B
F
C
D
A
E
B
A
B
E

Q

R
a
b
QYMQQOQV@
UYMQOQV@
Category
Case 1
(10mm≤Space A, C≤49mm)
Case 2
(Space A, C ≥ 49mm)
Installation Space
4 sides are
walls
Only 2 sides
are walls
Limitations on
the height of
the wall
(Refer to 4 side
walls)
Front
Front
Front
Front
Front
Front
Front
No limit to the height of the wall
No limit to the
height of the wall
Front
• The height of the wall on the front side must be 1500mm(59-1/16 inch) or less.
• The height of the wall on the inlet side must be 500mm(19-11/16 inch) or less.
• There is no limit to the wall on the side.
• If the height of the walls on the front and the inlet are higher than the limit, there
must be additional space on the front and the side.
- Additional Space on the inlet side by 1/2 of h1.
- Additional Space on the front side by 1/2 of h2
- h2 = A(Actual height) - 59-1/16
- h1 = B(Actual height) - 19-11/16
A≥10(13/32”) A≥50(1-31/32”)
B≥300(11-13/16”) B≥100(3-15/16”)
C≥10(13/32”) C≥50(1-31/32”)
D≥500(19-11/16”) D≥500(19-11/16”)
A≥10(13/32”) A≥50(1-31/32”)
B≥300(11-13/16”) B≥100(3-15/16”)
C≥10(13/32”) C≥50(1-31/32”)
D≥500(19-11/16”) D≥500(19-11/16”)
E≥20(25/32”) E≥100(3-15/16”)
A≥10(13/32”) A≥50(1-31/32”)
B≥300(11-13/16”) B≥100(3-15/16”)
C≥10(13/32”) C≥50(1-31/32”)
D≥500(19-11/16”) D≥500(19-11/16”)
E≥20(25/32”) E≥100(3-15/16”)
F≥600(23-5/8”) F≥500(19-11/16”)
A≥10(13/32”) A≥50(1-31/32”)
B≥300(11-13/16”) B≥100(3-15/16”)
C≥10(13/32”) C≥50(1-31/32”)
D≥300(11-13/16”) D≥100(3-15/16”)
E≥20(25/32”) E≥100(3-15/16”)
F
≥500(19-11/16”) F≥500(19-11/16”)
A≥10(13/32”)
B≥300(11-13/16”)
A≥200(7-7/8”)
B≥300(11-13/16”)
E≥400(15-3/4”)
