LG Multi V Installation Manual

Outdoor units Information
ENGLISH
Installation Manual 9
Unit 1 Outdoor Unit 2 Outdoor Unit
System
HP
Ton
Model
Product Charge
kg
lbs
Max. Connectable No. of Indoor Units
Net Weight
kg
lbs
Dimensions
(WxHxD)
mm
inch
Connecting
Pipes
Liquid Pipes[mm(inch)]
Gas Pipes[mm(inch)]
14 18 20
12 14 16
ARUN144BT3 ARUN168BT3 ARUN192BT3
ARUN144BT3 ARUN072BT3 ARUN072BT3
ARUN096BT3 ARUN121BT3
9.4 14.9 14.9
20.7 32.8 32.8
23 26 29
280 × 1 (190 × 1) + (280 × 1) (190 × 1) + (280 × 1)
617 × 1 (418 × 1) + (617 × 1) (418 × 1) + (617 × 1)
(1,240×1,680×760)×1 (920×1,680×760)×1 (920×1,680×760)×1
(1,240×1,680×760)×1 (1,240×1,680×760)×1
(48.8×66.1×29.9)×1 (36.2×66.1×29.9)×1 (36.2×66.1×29.9)×1
(48.8×66.1×29.9)×1 (48.8×66.1×29.9)×1
12.7(1/2) 15.88(5/8) 15.88(5/8)
28.58(1 1/8) 28.58(1 1/8) 28.58(1 1/8)
Outdoor units Information
n Heat pump
n Combination Ration(50~130%)
Notes: * We can guarantee the operation only within 130% Combination.
Outdoor Number Connection Capacity
Single outdoor unit 130%
Double outdoor units 130%
Triple outdoor units 130%
Power Supply: Outdoor Unit (3Ø, 208/230V, 60Hz)
Unit 1 Outdoor Unit
System
HP 81012
Ton 6810
Model
ARUN072BT3 ARUN096BT3 ARUN121BT3
ARUN072BT3 ARUN096BT3 ARUN121BT3
Product Charge
kg 5.5 9.4 9.4
lbs 12.1 20.7 20.7
Max. Connectable No. of Indoor Units 13 16 20
Net Weight
kg 190 x 1 280 × 1 280 × 1
lbs 418 x 1 617 × 1 617 × 1
Dimensions
(WxHxD)
mm (920×1,680×760)×1 (1,240×1,680×760)×1 (1,240×1,680×760)×1
inch (36.2×66.1×29.9)×1 (48.8×66.1×29.9)×1 (48.8×66.1×29.9)×1
Connecting
Pipes
Liquid Pipes[mm(inch)] 9.52(3/8) 9.52(3/8) 12.7(1/2)
Gas Pipes[mm(inch)] 19.05(3/4) 22.2(7/8) 28.58(1 1/8)
