General specifications
General
Power requirements Refer to the main label.
Power consumption
Refer to the main label.
Networked standby : 0,5 W
(If all network ports are activated.)
Dimensions (W x H x D) 290 mm x 349 mm x 370 mm
Net Weight (Approx.) 5,9 kg
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 60 %
Bus Power Supply 5 V
0
500 mA
Inputs
AUX IN 2,0 Vrms (1 kHz, 0 dB), 600 , RCA jack (L, R)
PORT. IN 1,2 Vrms (3.5 Ø jack)
MIC 30 mV
Tuner
FM Tuning Range 87,5 to 108,0 MHz or 87,50 to 108,00 MHz
CD
Frequency Response 40 to 20 000 Hz
Signal-to-noise ratio 75 dB
Dynamic range 80 dB
Amplier
Total output 2800 W
Front 470 W x 2 (6 at 1 kHz)
Surround 470 W x 2 (6 at 1 kHz)
Subwoofer 460 W x 2 (6 at 60 Hz)
THD 20 %
y
Design and specications are subject to change without notice.
