Installation
16
3. INSTALL THE SIM CARD.
Slide the SIM card into the SIM card holder. Make
sure that the SIM card is inserted properly and
that the gold contact area on the card is facing
downwards. To remove the SIM card, press down
lightly and pull it in the reverse direction.
4. INSTALL THE BATTERY.
Insert the bottom of the battery first into the
bottom edge of the battery compartment. Ensure
the battery contacts align with the terminals on
the phone. Push down the top of the battery until
it snaps into space. Do not force the battery.
5. REPLACE THE BATTERY COVER.
Lay the battery cover in place on the phone and
press it down until the latch clicks.
To remove the SIM card
To insert the SIM card
The metal contact of the SIM card can be
easily damaged by scratches. Pay special
attention to the SIM card while handling.
Follow the instructions supplied with the SIM
card.
2
1
2
1
1
