LG W2243S User Manual

Specifications W2343S
A23A23
NOTE
Information in this document is subject to change without notice.
Display
Sync Input
23 inches (58.4 cm) Flat Panel Active matrix-TFT LCD Anti-
Glare coating
Visible diagonal size: 58.4 cm
0.266*0.266 mm pixel pitch
Horizontal Freq. 30 - 83 kHz (Automatic)
Vertical Freq. 56 - 75 Hz (Automatic)
Input Form Separate TTL, Positive/Negative
SOG (Sync On Green)
Video Input
Signal Input 15 pin D-Sub Connector
Input Form RGB Analog (0.7 Vp-p/ 75 ohm)
Resolution
Max VESA 1920 x 1080 @60 Hz
Recommend VESA 1920 x 1080 @60 Hz
Plug&Play
DDC 2B
Power
On Mode
: 45 W(Typ.)
Consumption
Sleep Mode ≤ 1 W
Off Mode ≤ 1 W
Dimensions
With Stand Without Stand
& Weight
Width 55.52 cm / 21.86 inches 55.52 cm / 21.86 inches
Height 41.85 cm / 16.48 inches 35.77 cm / 14.08 inches
Depth 19.80 cm / 7.80 inches 6.30 cm / 2.48 inches
Net 4.42 kg (9.82 lbs)
Tilt Range
Tilt -5˚~ 15˚
Power Input
AC 100-240V~ 50/60Hz 1.0A
Environmental
Operating Conditions
Conditions
Temperature 10˚C to 35 ˚C
Humidity 10 % to 80 % non-Condensing
Storage Conditions
Temperature -20˚C to 60 ˚C
Humidity 5 % to 90 % non-Condensing
Stand Base
Attached ( ), Detached ( O )
Power cord
Wall-outlet type or PC-outlet type

LG W2243S Specifications

General

3D	No
Pixel pitch	0.248 x 0.248 mm
Aspect ratio	16:9
Display diagonal	21.5 \
Sync-on-green (SOG)	Yes
Vertical scan range	56 - 75 Hz
Horizontal scan range	30 - 83 kHz
Contrast ratio (dynamic)	30000:1
Display number of colors	16.78 million colors
Display brightness (typical)	- cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	-
DVI-D ports quantity	0
Product color	Black
Compliance industry standards	DDC 2B
LED indicators	Power
Tilt angle range	-5 - 15 °
Panel mounting interface	- mm
Input current	1 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	40 W
Package depth	449 mm
Package width	582 mm
Package height	127 mm
Package weight	5500 g
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth (with stand)	198 mm
Height (with stand)	396 mm
Weight (with stand)	3800 g
Depth (without stand)	62 mm
Width (without stand)	516 mm
Height (without stand)	333 mm
Weight (without stand)	2900 g
