Lombardini 15 LD 440 Service Manual

76
7
UM 15LD 225-350-420-440 _ cod. ED0053031170 - 1° ed_rev. 00
USE
KÄYTTÖ
EMPLOI
BEDIENUNG
UTILISACION
Topping up and checking the oil level must be done with the engine switched off and
cool, and with the engine in a horizontal position.
The used engine oil can cause skin-cancer if kept frequently in contact for prolonged
periods.
If contact with oil cannot be avoided, wash carefully your hands with water and soap as
soon as possible.
Do not disperse the oil in the ambient, as it has a high pollution power.
Täyttö ja öljymäärän tarkistuksesta on tehtävä moottori sammutettuna ja viileä, ja
moottorin ollessa vaakasuorassa asennossa.
Moottorin jäteöljy saattaa aiheuttaa ihosyöpää jatkuvassa ja pitkäaikaisessa
kosketuksessa.
Ellei kosketusta öljyyn voida välttää, pese kädet huolellisesti vedellä ja saippualla heti
kuin mahdollista.
Älä päästä jäteöljyä ympäristöön, sillä se on erittäin saastuttavaa.
Le ravitaillement et le contrôle du niveau d’huile doivent s’effectuer avec le moteur
éteint, froid et en position horizontale.
L’huile moteur épuisée peut être la cause de cancer de la peau si laissée fréquemment à
contact pour des périodes prolongées.
Si le contact avec l’huile est inévitable, se laver les mains à l’eau et savon avec soin dès
que possible.
Ne pas vidanger l’huile épuisée dans le milieu, car elle a un haut niveau de pollution.
Für die Vorgänge zum Tanken und zur Ölstandkontrolle muss sich der Motor in
horizontaler Position benden und ausgeschaltet und kalt sein.Schmieröl kann
Hautkrebs erzeugen, wenn es häug in Hautkontakt kommt.
Kann ein Kontakt nicht vermieden werden, sollte man sich so schnell wie möglich die
Hände gründlich waschen.
Wegen dem hohen Grad der Umweltverschmutzung, ist Sorge zu tragen, daß kein Öl
ins Erdreich.
El repostado y el control del nivel del aceite deben efectuarse con el motor apagado,
frío y en posición horizontal.
El aceite del motoe sucio (usaoo) puede ser causa de cancer de piel, si es
repetidamente ó prolongado su contacto.
Si el contacto con el aceite fuese inevitable, se aconseja lavarse adecuadamente las
manos con jabon lo antes posible.
Non dispersar o tirar el aceite usado: por ser de un alto nivel de contaminante.
USE - KÄYTTÖ - EMPLOI - BEDIENUNG - UTILISACION
