5 -41
▶ The filters are made of specially treated media with a rubber sealing strip bonded
around the sides. Take care not to damage the element during installation.
Notice
Cabin
air filters
Knobs
Filter
cover
(3) Replacing Cabin air filters
 Before servicing the filters, switch off the blower
and close all the cabin doors and windows.
 Cabin air filters are installed on the left and right-
hand side under the cabin roof.
 Unscrew the knobs under the roof and remove
the covers and filter elements as shown in the
right figure.
 Clean both filter chambers with a damp, lint-free
cloth.
 Replace the cabin air filters with a new one.
 Re-install the filter covers and tighten the knobs.
(2) Replacing Air cleaner element
(Dry type)
 Remove the cover and pull the primary element
straight out, ensuring the safety filter element
remains in place.
 Clean the inside of the air cleaner housing using
a clean damp cloth, being careful not to damage
the safety element.
 Check if there is damage inside the filter element
by using a light. If finding tiny cracks or small
holes in the filter element or the gasket is
damaged, change it with a new one.
 Insert the filter element deeply into the filter housing.
 Remove the dust of the evacuator valve and clean the inside of the cover.
 Assemble the cover with the evacuator valve facing downwards.
▶ Do not start the engine or close the hood if the filter element is not assembled..
Notice
Primary
element
Evacuator valve
Safety filter
element
