5-14. Every 3000hr check
(1) Cleaning
Emission related
parts
The following
items
are major engine
emission
related
parts. These items
are checked
and
cleaned
periodically. But
it is performed by
special eng
ine
service experts.
C
ontact
your
authorized local
dealer for check.
-. Fuel injector
-. DOC&DPF
-. Turb
ocharger
-. ECU
-. EGR valve
-. Sensors
-. Air Control Valve
(ACV)
Engine
Control Unit(ECU)
Turbochar
ger
Air Control Valve(ACV)
EGR Valve
DOC&DPF
227
229
