11
OWNER’S MANUAL
OWNER’S MANUAL
CR2-X BAR PRO Specifications
Appendix B: Technical Information
Power Requirements
CR2-X BAR PRO 24Vdc, 2.7A
Construction Features
Basic Design Rectangular
Display LEDs Four corner pieces on front grille
Volume level on center of front grille
Operating Temperature 0 – 45 ˚C
32 – 3 ˚F
Physical Properties
Height: 4.9 in / 24 mm
Width: 9.4 in / 492 mm
Depth: 4.8 in / 22 mm
Weight: 5. lb / 2.3 kg
Disclaimer
Since we are always striving to make our products better
by incorporating new and improved materials, components,
and manufacturing methods, we reserve the right to change
these specifications at any time without notice.
The “Running Man” figure is a registered trademark of LOUD
Audio, LLC.
All other brand names mentioned are trademarks or registered
trademarks of their respective holders, and are hereby
acknowledged.
©2023 LOUD Audio, LLC.
All Rights Reserved.
Acoustic Performance
Frequency Response (-0 dB) 58 Hz – 20 kHz
Horizontal Coverage Angle 80º
Vertical Coverage Angle 80º
Maximum SPL Peak 03 dB
Dynamic Range ≥90 dB
Signal-to-Noise Ratio ≥90 dB
Monitor Angle 5˚
Transducers
High Frequency 2x 2.75 in / 70 mm Full-Range Transducers
2x Passive Radiators
Amplifiers
Rated Power 60 watts peak
Design Class D
Input / Output
Input Type /8" / USB-C / Bluetooth
Output Type /8" Stereo Headphones
/8" Stereo TRS (To Sub)
Bluetooth Information
Bluetooth Protocol 5.0
Bluetooth Function Audio Streaming
Bit Depth / Sample Rate
Bit Depth 6-bit
Sample Rate 48 kHz
CR2-X Bar Pro Dimensions
WEIGHT
5.1 lb
2.3 kg
19.4 in / 492 mm
4.8 in / 122 mm
4.9 in
124 mm
