Mackie CR4BT User Manual

12
Multimedia Monitors w/ Bluetooth
®
Multimedia Monitors w/ Bluetooth
®
Appendix B: Technical Information
Bluetooth Information
Bluetooth Protocol 3.0
Bluetooth Function Audio Streaming
Construction Features
Basic Design Rectangular
Enclosure Construction Solid MDF
Finish Black vinyl wrap
Handles At <10 lb each, there
is no need for handles!
Port Configuration Custom-tuned
rear port tube
Damping Adiabatic batting
Display LED (Front) Power ring
(around volume knob)
Operating Temperature 0 – 40 ˚C
32 – 104 ˚F
Physical Dimensions and Weight
CR4BT
Dimensions
Height 8.8 in / 224 mm
Width 6.1 in / 155 mm
Depth 7.3 in / 185 mm
Weight 12.0 lb / 5.4 kg [pair]
CR5BT
Dimensions
Height 10.2 in / 259 mm
Width 6.9 in / 175 mm
Depth 9.0 in / 229 mm
Weight 15.0 lb / 6.8 kg [pair]
Disclaimer
LOUD Technologies is always striving to improve our products
by incorporating new and improved materials, components and
manufacturing methods. Therefore, we reserve the right to
change these specifications at any time without notice.
The Running Man is a registered trademark of LOUD
Technologies Inc. This manual also contains names and
marks of other companies which belong to those respective
companies, and are hereby acknowledged.
©2015 LOUD Technologies Inc. All Rights Reserved.
CRBT Series Specifications
Acoustic Performance
Frequency Response (–3 dB) 70 Hz – 20 kHz [CR4BT]
60 Hz – 20 kHz [CR5BT]
Frequency Response (–10 dB) 60 Hz – 20 kHz [CR4BT]
50 Hz – 20 kHz [CR5BT]
Maximum SPL Peak Per Pair 100 dB [CR4BT]
103 dB [CR5BT]
Crossover Frequency 3 kHz
Transducers
Low Frequency 4.0 in / 102 mm polypropylene-
coated woofer [CR4BT]
5.0 in / 127 mm polypropylene-
coated woofer [CR5BT]
High Frequency 0.75 in / 19 mm silk dome tweeter
Amplifiers
Rated Power 28 watts rms
50 watts peak
Design Class AB
Input / Output
Input Type Balanced / unbalanced 1/4" TRS,
unbalanced RCA [Rear]
1/8" TRS [Front]
Input Impedance 20 kΩ, balanced bridging;
10 kΩ unbalanced
Output Type 1/8" stereo headphones [Front]
Power Requirements
United States 120 VAC, 60 Hz
Europe 220–240 VAC, 50/60 Hz
Korea 220 VAC, 60 Hz
Japan 100 VAC, 50/60 Hz
Power Consumption 72 watts with music, loud mix
Note: CRBT Series monitors do not support multiple voltage
configurations. Make sure the voltage rating for your particular
model (as indicated on the rear panel) corresponds with your
local AC mains voltage.

Mackie CR4BT Specifications

General

Tweeter	Yes
Speaker type	2-way
Woofer diameter	102 mm
Tweeter diameter	19 mm
Number of drivers	2
Speaker placement	Tabletop/bookshelf
Audio output channels	2.0 channels
Number of tweeter drivers	1
Woofer diameter (imperial)	4 \
Tweeter diameter (imperial)	0.75 \
Bluetooth version	3.0
Connectivity technology	Wired & Wireless
AC input voltage	100 - 120/220 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	72 W
Frequency range	60 - 20000 Hz
RMS rated power	28 W
Crossover frequency	3000 Hz
Peak Music Power Output (PMPO)	50 W
Product color	Black
Volume control	Rotary
Housing material	MDF
Recommended usage	Studio
Quantity per pack	1 pc(s)
Amplifier class	A/B

Weight and Dimensions

Depth	185 mm
Width	155 mm
Height	224 mm
Weight	5400 g
