Match the direction of the arrow on the blade to that of the
arrow on the wheels.
Position the blade around the wheels and insert the other
side of the blade within the upper holder and lower holder
until the blade back contacts the bottom of the upper holder
and lower holder.
Start and stop the tool two or three times to make sure that
the blade runs properly on the wheels.
CAUTION:
• While making sure that the blade runs on the wheels
properly, keep your body away from the blade area.
To remove the blade, follow the installation procedure in
reverse.
CAUTION:
• When turning the blade tightening lever clockwise to
release the tension on the blade, point the tool
downward because the blade may come off
unexpectedly.
Adjusting the protrusion of stopper plate
Protrusion of the stopper plate to the blade can be adjusted.
In the ordinary operation, protrude the stopper plate to the A
side fully.
When the stopper plate strikes against the obstacles like a
wall or the like at the finishing of a cut, loosen two screws
and slide it to the B side in the figure.
After sliding the stopper plate, secure it by tightening two
screws firmly.
1. Saw blade
2. Bearing
3. Upper holder
4. Lower holder
1
2
3
4
005900
1. Upper holder
2. Lower holder
3. Wheel
4. Press
1
3
2
4
005901
1. Screw
2. Stopper plate
3. Blade
1
2
3
B
A
005902
