6
ENGLISH
Explanation of general view
1 To avoid kickback, do support
board or panel near the cut.
2 Don’t support board or panel
away from the cut.
3 A typical illustration of proper
hand support and workpiece
support.
4 Hex wrench
5Shaft lock
6 Tighten
7 Loosen
8 Saw blade
9 Outer flange
10 Inner flange
11 Outer flange
12 Hex socket head bolt
13 Saw blade
14 Setting protuberances
15 Hex socket head bolt
(For adjusting riving knife)
16 Cutting depth
17 Thumb nut
18 Thumb nut
19 For 45° bevel cuts
20 For straight cuts
21 Base plate
22 Lock-off button
23 Switch trigger
24 Vacuum cleaner
25 Limit mark
26 Brush holder cap
27 Screwdriver
SPECIFICATIONS
Model 5604R
Blade diameter ............................................. 165 mm
Max. cutting depth
At 90° .......................................................... 54 mm
At 45° .......................................................... 35 mm
No load speed (min
-1
) ...................................... 5,000
Overall length ............................................... 320 mm
Net weight ........................................................3.6 kg
• Due to our continuing program of research and
development, the specifications herein are subject
to change without notice.
• Note: Specifications may differ from country to
country.
Intended use
The tool is intended for performing lengthways and
crossways straight cuts and miter cuts with angles to
45° in wood while in firm contact with the workpiece.
Power supply
The tool should be connected only to a power supply
of the same voltage as indicated on the nameplate,
and can only be operated on single-phase AC supply.
They are double-insulated in accordance with Euro-
pean Standard and can, therefore, also be used from
sockets without earth wire.
SAFETY INSTRUCTIONS
Warning! When using electric tools, basic safety
precautions should always be followed to reduce
the risk of fire, electric shock and personal injury,
including the following. Read all these instruc-
tions before attempting to operate this product
and save these instructions.
For safe operation:
1. Keep work area clean
Cluttered areas and benches invite injuries.
2. Consider work area environment
Don’t expose power tools to rain. Don’t use
power tools in damp or wet locations. Keep work
area well lit. Don’t use power tools in presence of
flammable liquids or gases.
3. Guard against electric shock
Prevent body contact with grounded surfaces
(e.g. pipes, radiators, ranges, refrigerators).
4. Keep children away
Do not let visitors contact tool or extension cord.
All visitors should be kept away from work area.
5. Store idle tools
When not in use, tools should be stored in dry,
high, or locked-up place, out of the reach of chil-
dren.
6. Don’t force tool
It will do the job better and safer at the rate for
which it was intended.
7. Use right tool
Don’t force small tools or attachments to do the
job of a heavy duty tool. Don’t use tools for pur-
poses not intended; for example, don’t use circu-
lar saw for cutting tree limbs or logs.
8. Dress properly
Do not wear loose clothing or jewelry. They can
be caught in moving parts. Rubber gloves and
non-skid footwear are recommended when work-
ing outdoors. Wear protective hair covering to
contain long hair.
9. Use safety glasses and hearing protection
Also use face or dust mask if cutting operation is
dusty.
10. Connect dust extraction equipment
If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used.
11. Don’t abuse cord
Never carry tool by cord or yank it to disconnect it
from receptacle. Keep cord from heat, oil and
sharp edges.
12. Secure work
Use clamps or a vise to hold work. It’s safer than
using your hand and it frees both hands to oper-
ate tool.
13. Don’t overreach
Keep proper footing and balance at all times.
To Next Page
