16 ENGLISH
Adjusting the handle/hanger
position
Adjustthehandleandhangerpositiontoobtaincom-
fortable handling of the tool.
For DUR190U and DUR191U
Adjustthehandle/hangerpositionsothatthetool
comes within the range as shown below.
1
2
3
1 The hanger position from the ground
2 The cutting tool position from the ground
3 The horizontal distance between the hanger and the
unguarded part of the cutting tool
Loosen the hex socket head bolts on the bottom of the
handle holder. Move the handle to a comfortable work-
ing position and then tighten the bolts.
1
2
3
►1. Handle holder 2. Hex socket head bolt 3. Handle
Loosen the Hex socket head bolts on the hanger. Move
the hanger to a comfortable working position and then
tighten the bolts.
1
2
►1. Hex socket head bolt 2. Hanger
For DUR190L and DUR191L
Loosen the hex socket head bolts on the handle. Move
the handle to a comfortable working position and then
tighten the bolts.
1
2
►1. Hex socket head bolt 2. Handle
Loosen the hex socket head bolt on the hanger. Move
the hanger to a comfortable working position and then
tighten the bolt.
1
2
►1. Hex socket head bolt 2. Hanger

Makita DC18RC Specifications

General

Input voltage	220-240 V
Output current	9 A
Input frequency	50/60 Hz
Battery recharge time	0.36 h
Battery voltage	18 V
Battery capacity	3000 mAh
Product type	Battery charger
Product color	Black
Brand compatibility	Makita
Compatible battery sizes	-
Number of batteries supported	1

Weight and Dimensions

Depth	156 mm
Width	190 mm
Height	84 mm
Weight	750 g
Cable length	2 m
