10 ENGLISH
1
►1. Mode indicator
The mode indicator lights up in green when the tool is
runningin"hightorquemode".
If the tool is operated with excessive load, the mode
indicator will blink in green. The mode indicator stops
blinkingandthenlightsuporturnsoffifyoureducethe
load on the tool.
Mode indicator status Operation
mode
On Off Blinking
High speed
mode
Hightorque
mode
Overload
alert
Adjusting depth of cut
CAUTION: After adjusting the depth of cut,
always tighten the lever securely.
Loosen the lever and move the base up or down to align the
pointerwithyourdesireddepthonthedepthguide.Atthe
desireddepthofcut,securethebasebytighteningthelever.
For cleaner, safer cuts, set cut depth so that no more
thanonebladetoothprojectsbelowworkpiece.Using
proper cut depth helps to reduce potential for danger-
ousKICKBACKSwhichcancausepersonalinjury.
1
2
►1. Pointer 2. Lever
You can read the cut depth with the scale on the lower guard.
3
2
1
►1. Lower guard 2. Bottom of the tool base 3. Scale
Bevel cutting
CAUTION: After adjusting the bevel angle,
always tighten the lever and clamping screw
securely.
Loosen the lever and clamping screw. Set for the
desiredanglebytiltingaccordingly,thentightenthe
leverandclampingscrewsecurely.
1
2
►1. Lever 2. Clamping screw
Usethestopperwhenyoudoprecise45°anglecutting.
Fullyturnthestopperasillustrateddependingon0°-
45° bevel cut or 0° - 50° bevel cut.
1
0° - 45°
0° - 50°
►1. Stopper
