15 ENGLISH
MAINTENANCE
CAUTION: Always be sure that the tool is
switched o󰀨 and the battery cartridge is removed
before attempting to perform inspection or
maintenance.
TomaintainproductSAFETYandRELIABILITY,
repairs,anyothermaintenanceoradjustmentshould
beperformedbyMakitaAuthorizedorFactoryService
Centers,alwaysusingMakitareplacementparts.
Cleaning the tool
Cleanthetoolbywipingo󰀨dustwithadryclothorone
dipped in soapy water and wrung out.
NOTICE: Never use gasoline, benzine, thinner,
alcohol or the like. Discoloration, deformation or
cracks may result.
Shear blade maintenance
Beforetheoperationoronceperhourduringoperation,
applylow-viscosityoil(machineoil,orspray-typelubri-
catingoil)totheshearblades.
►Fig.30
Afteroperation,removedustfrombothsidesofthe
shearbladeswithawiredbrush,wipeito󰀨withacloth
andthenapplylow-viscosityoil(machineoil,orspray-
typelubricatingoil)totheshearblades.
►Fig.31
NOTICE: Do not wash the shear blades in water.
Doingsomaycauserustordamagetothetool.
NOTICE: Dirt and corrosion cause excessive
friction of the shear blades and shorten the oper-
ating time per battery charge.
Storage
Thehookholeinthetoolbottomisconvenientforhang-
ingthetoolfromanailorscrewonthewall.
Attachthebladecovertotheshearbladessothatthe
shearbladesarenotexposed.Storethetooloutofthe
reachofchildren.Storethetoolinaplacenotexposed
to moisture or rain.
►Fig.32: 1. Hole
TROUBLESHOOTING
Beforeaskingforrepairs,conductyourowninspectionrst.Ifyoundaproblemthatisnotexplainedinthemanual,
donotattempttodismantlethetool.Instead,askMakitaAuthorizedServiceCenters,alwaysusingMakitareplace-
mentpartsforrepairs.
State of abnormality Probable cause (malfunction) Remedy
Motor does not run. Batterycartridgeisnotinstalled. Installthebatterycartridge.
Battery problem (under voltage) Rechargethebattery.Ifrechargingisnote󰀨ective,
replacebattery.
Thedrivesystemdoesnotwork
correctly.
Askyourlocalauthorizedservicecenterforrepair.
Motorstopsrunningafteralittleuse. Battery'schargelevelislow. Rechargethebattery.Ifrechargingisnote󰀨ective,
replacebattery.
Overheating. Stopusingoftooltoallowittocooldown.
TooldoesnotreachmaximumRPM. Battery is installed improperly. Installthebatterycartridgeasdescribedinthis
manual.
Battery power is dropping. Rechargethebattery.Ifrechargingisnote󰀨ective,
replacebattery.
Thedrivesystemdoesnotwork
correctly.
Askyourlocalauthorizedservicecenterforrepair.
Shearbladesdonotmove:
Stopthemachineimmediately!
Foreignobjectsarecaughtbetweenthe
shear blades.
Switcho󰀨thetoolandremovethebatterycartridge,
andthenremovetheforeignobjectsusingtools
suchaspliers.
Thedrivesystemdoesnotwork
correctly.
Askyourlocalauthorizedservicecenterforrepair.
Abnormalvibration:
Stopthemachineimmediately!
Shear blades are broken, bent or worn. Replacetheshearblades.
Thedrivesystemdoesnotwork
correctly.
Askyourlocalauthorizedservicecenterforrepair.
Shearbladesandmotorcannotstop:
Remove the battery immediately!
Electricmalfunction. Removethebatteryandaskyourlocalauthorized
servicecenterforrepair.
